Gate Valve

Gate Valve Non-Rising and Rising Type That Conforms to (IS:14846/2000)                   Standards. Our caters to The Requirement of Diverse Industries and Domestic Sectors. Offered in Different Technical Specifications Like Sizes, Range and Pressure Rating, Each Valve is Specially Tested Under Strict Supervision and Quality Control. Unique Design, Superb Production and Hard Gained Field Experience Have Made These Valves Reliable.

Gate Valves are manufactured and exported to API Std. 600, API 603, BS 1414 and tested to API 598. It is commonly used where minimum pressure drop and bidirectional on-off service is required.

Specifications:

  • Normal Standard: IS: 14846
  • Other Standard: BS Din & As Per Client Requirement.
  • Pressure Rating: PN- 1.6 (Size-50MM to  400MM)                                                                                                                  PN- 1.0 (Size-450MM to 1200MM)
  • Operational Arrangement: Hand Wheel, Gear Box For Manual Operation.
  • Special Features: Drain Plug, Back Seat Bush, Indicator, Chain Wheel & Locking Arrangement.

Other Standard

  • Standard: API 600 / BS-1414
  • Face To Face Dimensions: ASME B 16.10
  • Size Range: 15mm to 600 mm
  • Pressure Rating: Class150/300/600/900/1500/2500

Material of Construction:

  • From bar stock in carbon steel or stainless steel (304, 316,304L. 316L. 321), Alloy 20, Hastelloy B & C.
  • Castings in carbon steel to ASTM A216 Gr. WCB, WCC, LCB, LCC.
  • Casting in stainless steel to ASTM A 351 Gr. CF8/CF 8M/CF 8C/CF3/CF 3M Alloy 20, Hastelloy B & C.
  • Castings in C.I. to I.S. 210 Gr. FG200/220/260.
  • Castings in Alloy Steel to ASTM A 217 C5, WC6, WC9, WC12.Design
